Large Diameter Solenoid Valve

Appearance and Structure

The Large Diameter Solenoid Valve appearance and design of the large-diameter electromagnetic valve are compact and reasonable, facilitating installation and maintenance. Its large-diameter design provides a spacious fluid passage, reducing the resistance of fluid flow and improving the flow efficiency. The internal structure of the valve has been meticulously optimized to ensure the smoothness and uniformity of the fluid when passing through the valve.

Working Principle

When the coil of Large Diameter Solenoid Valve is energized, a strong electromagnetic force is generated, attracting the valve core to move, thereby opening the valve and allowing the fluid to flow smoothly; when the coil is de-energized, the electromagnetic force disappears, and the valve core returns to its initial position under the action of a spring or other reset devices, closing the valve and blocking the flow of the fluid. This simple and reliable working principle enables the electromagnetic valve to achieve precise fluid control. Technical Specifications

● Pipe diameter range: Usually from DN50 and above, various pipe diameters can be provided according to different application requirements.

● Working pressure: Capable of withstanding high working pressure, generally ranging from 1 to 10 MPa, depending on the model and material.

● Working temperature: The applicable working temperature range is wide, able to operate normally within -20℃ to 200℃. Special models can also adapt to higher or lower temperature environments.

● Power supply voltage: Supports multiple power supply voltages, such as 24V, 110V, 220V, etc., facilitating compatibility with different control systems.

Specification Of Large Diameter Solenoid Valve:

Product Feature:

1. High-flow control: The Large Diameter Solenoid Valve design enables this solenoid valve to handle a large volume of fluid, meeting the demand for high flow in industrial production and commercial systems, thereby enhancing production efficiency.

2. Quick response: Utilizing advanced electromagnetic control technology, the Large Diameter Solenoid Valve can achieve opening and closing actions instantaneously, with a short response time, ensuring timely control of the fluid.

3. Reliable sealing: Equipped with high-performance seals, Large Diameter Solenoid Valve can effectively prevent fluid leakage, ensuring the safety and stability of the system. Even in high-pressure environments, it can maintain good sealing performance.

4. Strong corrosion resistance: TheLarge Diameter Solenoid Valve body is manufactured from high-quality corrosion-resistant materials, such as stainless steel and brass, which can resist various chemical substances and corrosive media, extending the service life of the solenoid valve.

5. Easy installation and maintenance: The Large Diameter Solenoid Valve structural design is reasonable, and the installation process is simple and convenient. At the same time, its modular design makes maintenance and replacement of components more convenient, reducing maintenance costs and downtime.

6. Various control methods: According to different application requirements, you can choose open or closed control methods, and Large Diameter Solenoid Valve can also be integrated with an automated control system to achieve remote control and intelligent management.

1. Industrial sector

● Chemical industry: Large Diameter Solenoid Valve Used for the transportation and control of various liquids and gases in the chemical production process, such as the treatment of corrosive media like acids, bases, and salts.

● Oil and gas industry: In the processes of oil extraction, refining, and gas transportation, Large Diameter Solenoid Valve used to control the flow and pressure of fluids like crude oil and natural gas.

● Power industry: Applied in cooling systems of power stations, boiler feedwater systems, etc., for precise control of water and steam fluids.

● Metallurgical industry: In the processes of steel smelting and non-ferrous metal processing, Large Diameter Solenoid Valve used to control the supply of cooling fluids and lubricants.

2. Business sector

● Central air conditioning system: Large Diameter Solenoid Valve Used to regulate the flow of chilled water and cooling water in the central air conditioning systems of large commercial buildings, achieving energy conservation and temperature control.

● Water supply and drainage system: In urban water supply, drainage, and wastewater treatment systems, Large Diameter Solenoid Valve used to control the on-off and flow regulation of water flow.

● Fire protection system: As the key control equipment for fire sprinkler systems and fire curtains, ensuring timely and accurate water supply in case of a fire.

3. Other sectors

● Food and beverage industry: Large Diameter Solenoid Valve Used for the transportation and control of various liquid raw materials in food processing, meeting hygiene standards requirements.

● Pharmaceutical industry: In the production process of drugs, Large Diameter Solenoid Valve used for precise flow control and aseptic transportation of liquid drugs and solvents.
