Semi-direct acting solenoid valve

Semi-direct acting solenoid valve from Qimao Pneumatic factory

● Structure & Material:

○The valve body usually made of high quality metal materials, such as stainless steel and brass, it possess excellent corrosion resistance and mechanical strength.

○The sealing components made of high performance rubber or plastic materials to ensure the sealing performance of the valve and prevent the leakage of the medium.

○The electromagnetic coil uses high quality copper module, with excellent insulation properties, and can maintain stable electromagnetic force during long-term operation.

○The coil uses high-purity copper module, with excellent insulation properties, and can keep stable electromagnetic force while long-term operation.

Working principle

● Low-pressure startup stage: When the system pressure is low, the operation mode of the solenoid valve is similar to that of a direct-acting solenoid valve. After being energized, the electromagnetic coil generates electromagnetic force, which directly acts on the valve core, overcoming the spring force and the medium pressure, causing the valve core to move upwards and opening the valve, allowing the medium to flow.

● High-pressure operation stage: When the system pressure increases, the solenoid valve operates using the pilot principle. The electromagnetic force opens the pilot hole, creating a pressure between the upper and lower chambers . Under the difference pressure, the main valve core is pushed, so make the valve to open. When the power is cut off, the electromagnetic force disappears, the valve core is re-start by the spring force and the medium pressure, close the valve.

Specification Of Semi-direct acting solenoid valve:

Product Feature:

● Pressure range adaptability: Semi-direct acting solenoid valve can start in low-pressure environments, under high pressure conditions stably, adapt to different pressure working condition.

● Rapid response: Our solenoid valve has a fast response , make the valve to be opened and closed in a short time, match the requirements for the fluid control.

● High sealing performance: This solenoid valve uses high quality sealing materials and structures to ensure good sealing, when the valve closed, ensure the system safety and stability.

● Strong durability: The valve body and inner components are with good quality material, and with strict requirements, with good anti wear and anti corrosion properties, with long workable life.

● Energy-saving and efficient: During working, the electromagnetic coil use less power, reducing energy and improving the operational efficiency.

● Industrial Automation: For industrial production system, the solenoid valve is used to control the transportation and various fluids, such as the air source control of pneumatic equipment and the flow regulation of hydraulic systems, to ensure the automation and  control the production process.

● HVAC System: In the HVAC system, Semi-direct acting solenoid valve is used to control the refrigerants flow , hot water line or cold water line, and adjust the indoor temperature and humidity, achieving the comfortable indoor environment.

● Water Treatment Industry: In the water treatment, it is used to control the flow direction, flow rate and water pressure, such as wastewater management and the water flow regulation in the pure water production process.

● Food and Beverage Industry: In the food and beverage production , it is used to control the transportation and mix raw materials liquid, to ensure the hygiene and safety in the production process.
