Industrial automation solenoid valve

The Industrial Automation Solenoid Valves makes it on-off, flow rate and pressure of the fluid can be precisely controlled to meet the diverse demands of industrial production. The electromagnetic drive mode enables the valve to complete the opening or closing action in an instant, greatly improving the production efficiency. Made of high-quality materials, it features excellent wear resistance and corrosion resistance, and is suitable for harsh industrial environments. It has multiple specifications and interface types, and can be seamlessly integrated with different industrial automation systems.
Model:QM1213

Send Inquiry

Product Description

Industrial Automation Solenoid Valve


Industrial Automation Solenoid Valve is mainly composed of electromagnetic coils, valve cores, valve bodies, sealing parts and other components. When the electromagnetic coil is energized, it will generate a strong magnetic field, driving the valve core to move and thereby changing the working state of the valve. The valve body provides a flow channel for the fluid, while the seal ensures that there is no leakage during the operation of the valve.

Working principle

When the electromagnetic coil is connected to the power supply, an electromagnetic force is generated, which attracts the valve core to overcome the resistance of the spring and move, opening the valve and allowing the fluid to pass through. When the power supply is cut off, the electromagnetic force disappears, the valve core returns to its original position under the action of the spring force, the valve closes, and the fluid flow is prevented. Some solenoid valves can also achieve more precise control of fluid flow and direction by changing the magnitude and direction of the current.




Specification Of Industrial Automation Solenoid Valve :


Valve function: 5/3
Medium: Compressed Air

Working Pressure:

0-1.6bar
Voltage:
DC 24V
Protection Insulation class
H
Protection Class
IP65
Power: 1.2W
Maximum Operating Frequency

Off load 50/sec

Power Connector Style: L style
Working Temp: -10℃~+80℃
Working Life: >30 million













Product Feature:


Improve production efficiency

The rapid response speed and precise control capability make fluid control in industrial production processes more efficient, significantly shortening the production cycle and enhancing the overall production efficiency. For instance, in an automated production line, solenoid valves can rapidly and accurately control the transportation and distribution of materials, achieving continuous and efficient production.

Reduce operating costs

Highly automated control reduces manual intervention and lowers labor costs. Meanwhile, precise flow and pressure control can prevent fluid waste, reduce energy consumption and raw material costs. In addition, its high reliability and long service life reduce the frequency of equipment maintenance and replacement, further lowering operating costs.

Enhance the stability of the system

Industrial Automation Solenoid Valve has good repeatability and stability, and can maintain reliable performance during long-term continuous operation and in complex industrial environments. This helps to reduce equipment failures and downtime, enhance the overall stability and reliability of industrial automation systems, and ensure the continuity of the production process and the consistency of product quality.

Facilitate system integration

Compact structure and small size, Industrial Automation Solenoid Valve is easy to install and integrate with various industrial automation equipment and control systems. Its standardized interfaces and communication protocols enable it to be conveniently connected to devices such as PLCS and sensors, achieving intelligent remote control and monitoring.以





Product Applications:


Chemical and petrochemical industry

● Raw material transportation and blending: In chemical production, precisely control the transportation and mixing ratios of various chemical raw materials to ensure product quality and production safety.

● Reactor control: Adjust the pressure, temperature and flow rate inside the reactor to achieve precise control of chemical reactions, thereby enhancing production efficiency and product quality.

The food and beverage industry

● Filling production line: Accurately control the filling volume and flow rate of liquids such as beverages and foods to ensure product consistency and hygiene standards.

● Food processing process: Control the supply of fluids such as steam, water, and edible oil to meet the demands of different food processing techniques.

Pharmaceutical industry

● Preparation and transportation of pharmaceutical solutions: In pharmaceutical production, precisely control the proportion and transportation of pharmaceutical solutions to ensure the quality and safety of drugs.

● Clean workshop environmental control: Regulate the air flow and pressure within the clean workshop to maintain a good production environment and prevent the contamination of drugs.

Automobile manufacturing industry

● Coating production line:  Industrial Automation Solenoid Valve control the spraying flow and pressure of the coating to ensure the quality and uniformity of automotive coating.

● Engine testing system: Precisely control the supply of fluids such as fuel and air to achieve accurate testing and debugging of engine performance.

Electronic manufacturing industry

● Semiconductor production: During the semiconductor manufacturing process, the precise control of the delivery of high-purity gases and liquids ensures the high precision and quality of chip manufacturing.

● Circuit board cleaning: Industrial Automation Solenoid Valve control the flow rate and spray pressure of the cleaning solution to achieve efficient cleaning and drying of circuit boards.
